CytoFLEX LX 流式细胞仪
CytoFLEX LX 流式细胞仪是CytoFLEX 平台的延伸产品。此型号采用多达 6 个激光和 21 个颜色参数扩展研究的可能性。六个空间分离的激光可以让面板在整个光谱中扩散，减少串扰和光谱重叠。- 有两个系列可用，即紫外线-紫-蓝-黄绿-红-红外线 (U-V-B-Y-R-I) 系列和近紫外线-紫-蓝-黄绿-红-红外线 (U-V-B-Y-R-I) 系列
- 有四个激活的激光和 14 个颜色参数可以选择的仪器，可选择在未来购买密钥激活其他激光和颜色
- 对于需要更高处理量的应用，可选板式进样器模块，它仅可在受管制的环境中下使用，软件所包含的工具遵守《美国联邦法规》第 21 章第 11 款的规定
CytoFLEX LX 流式细胞仪功能
选择 CytoFLEX LX 型号
技术文件
相关产品或零部件
C06147, CytoFLEX Daily IR QC Fluorospheres
CytoFLEX Daily IR Fluorospheres is a suspension of fluorescent microspheres used for daily verification of the IR laser containing CytoFLEX S and CytoFLEX LX Flow Cytometers optical alignment and fluidics system.
B51503, CytoFLEX Sheath Fluid, 1 x 10 L
A nonionic, non-fluorescent, and azide-free sheath fluid for use on CytoFLEX flow cytometers.
LAB EQUIP,TEST TUBE, 12 X 75 MM, POLYPROPYLENE, BLUE (250/PK)
Sample Tubes for FC 500 and EPICS™ XL™ Flow Cytometers.
CytoFLEX LX Upgrade from N3-V5-B3-Y5-R3-I0 to N3-V5-B3-Y5-R3-I2
Activation key to upgrade the CytoFLEX LX N3-V5-B3-Y5-R3-I0 flow cytometer with additional parameters. Upon installation the instrument will have 6 active lasers (375 nm, 405 nm, 488 nm, 561 nm, 638 nm, 808 nm) and 21 channels for fluorescence detection in the N3-V5-B3-Y5-R3-I2 configuration.
CytoFLEX LX Upgrade from U3-V5-B3-Y3-R0-I0 to U3-V5-B3-Y5-R3-I0
Activation key to upgrade the CytoFLEX LX U3-V5-B3-Y3-R0-I0 flow cytometer with additional parameters. Upon installation the instrument will have 5 active lasers (355 nm, 405 nm, 488 nm, 561 nm, 638 nm) and 19 channels for fluorescence detection in the U3-V5-B3-Y5-R3-I0 configuration.
CytoFLEX LX Upgrade from U3-V5-B3-Y0-R3-I0 to U3-V5-B3-Y5-R3-I2
Activation key to upgrade the CytoFLEX LX U3-V5-B3-Y0-R3-I0 flow cytometer with additional parameters. Upon installation the instrument will have 6 active lasers (355 nm, 405 nm, 488 nm, 561 nm, 638 nm, 808 nm) and 21 channels for fluorescence detection in the U3-V5-B3-Y5-R3-I2 configuration.
CytoFLEX LX Upgrade from U3-V5-B3-Y3-R0-I0 to U3-V5-B3-Y5-R3-I2
Activation key to upgrade the CytoFLEX LX U3-V5-B3-Y3-R0-I0 flow cytometer with additional parameters. Upon installation the instrument will have 6 active lasers (355 nm, 405 nm, 488 nm, 561 nm, 638 nm, 808 nm) and 21 channels for fluorescence detection in the U3-V5-B3-Y5-R3-I2 configuration.
CytoFLEX LX Upgrade from U3-V5-B3-Y5-R3-I0 to U3-V5-B3-Y5-R3-I2
Activation key to upgrade the CytoFLEX LX U3-V5-B3-Y5-R3-I0 flow cytometer with additional parameters. Upon installation the instrument will have 6 active lasers (355 nm, 405 nm, 488 nm, 561 nm, 638 nm, 808 nm) and 21 channels for fluorescence detection in the U3-V5-B3-Y5-R3-I2 configuration.
CytoFLEX LX Upgrade from U3-V5-B3-Y0-R3-I0 to U3-V5-B3-Y5-R3-I0
Activation key to upgrade the CytoFLEX LX U3-V5-B3-Y0-R3-I0 flow cytometer with additional parameters. Upon installation the instrument will have 5 active lasers (355 nm, 405 nm, 488 nm, 561 nm, 638 nm) and 19 channels for fluorescence detection in the U3-V5-B3-Y5-R3-I0 configuration.
CytoFLEX LX Flow Cytometer FAQs
What is the CytoFLEX LX Flow Cytometer used for?
The CytoFLEX LX Flow Cytometer is designed for advanced flow cytometry applications requiring high-parameter analysis and flexible configuration options.
How many color parameters can the CytoFLEX LX Analyzer detect?
The system supports up to 21 color parameters, depending on configuration.
How does the CytoFLEX LX Analyzer support complex panel design?
Six spatially separated lasers allow users to distribute fluorochromes across the spectrum, helping reduce cross talk and making it easier to design high-parameter panels.
What types of research applications is the CytoFLEX LX Analyzer suited for?
The system is designed to support a wide range of research applications that benefit from multi-parameter analysis and flexible laser configurations.
What configuration options are available for the CytoFLEX LX Analyzer?
Two series are available: UV-Violet-Blue-Yellow Green-Red-IR (U-V-B-Y-R-I) and Near UV-Violet-Blue-Yellow Green-Red-IR (N-V-B-Y-R-I).
What is the minimum configuration available for the CytoFLEX LX Analyzer?
Instruments are available with as few as four activated lasers and 14 color parameters.
Can the CytoFLEX LX Analyzer be upgraded over time?
Yes, additional lasers and detection channels can be activated as needed through the purchase of activation keys.
How does the CytoFLEX LX Analyzer support evolving research needs?
The platform allows users to start with a smaller configuration and expand capabilities over time, supporting changing experimental requirements.
Does the CytoFLEX LX Analyzer support high-throughput workflows?
Yes, an optional plate loader module is available for higher throughput applications.
Can the CytoFLEX LX Analyzer be integrated into automated workflows?
The system can be used with an optional plate loader and integrated with other instruments to support automated sample processing and data acquisition workflows.
What software is used with the CytoFLEX LX Analyzer?
All instruments in the CytoFLEX platform utilize CytExpert for CytoFLEX Analyzer Acquisition and Analysis Software.
Is the software suitable for regulated environments?
Yes, the software includes tools to support 21 CFR Part 11 compliance.
What makes the CytoFLEX LX Analyzer different from other systems in the platform?
The CytoFLEX LX expands the platform’s capabilities by offering higher- parameter configurations and additional laser options.
Can the CytoFLEX platform be upgraded to spectral flow cytometry?
Yes. Compatible CytoFLEX platforms can be upgraded with the CytoFLEX mosaic Spectral Detection Module, allowing researchers to add spectral flow cytometry capabilities without replacing their existing instrument.
